Product Summary

The AD680ARZ is a band gap voltage reference that provides a fixed 2.5 V output from inputs between 4.5 V and 36 V.

Parametrics

Absolute maximum ratings: (1)VIN to Ground:36V ; (2)Power Dissipation(25℃):500mW ; (3)Storage Temperature:-65℃ to +125℃; (4)Lead Temperature (Soldering, 10 sec):300℃; (5)Package Thermal Resistance θJA (All Packages):120℃/W.

Features

Features: (1)Low quiescent current at 250μA max ; (2)Laser trimmed to high accuracy:2.5 V ± 5 mV max (AN, AR grades) ; (3)Trimmed temperature coefficient:20 ppm/℃ max (AN, AR grades) ; (4)Low noise at 8μV p-p from 0.1 Hz to 10 Hz ; (5)250 nV/√Hz wideband ; (6)Temperature output pin (N, R packages).

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD680ARZ
AD680ARZ

IC VREF SERIES PREC 2.5V 8-SOIC
Data Sheet
0-1: $4.49
1-10: $4.05
10-100: $3.33
100-250: $3.06
250-500: $2.79
500-1000: $2.43
1000-2500: $2.40
